Ezviz Ty1 Pro 2k⁺ Indoor Smart Wifi Baby/pet Monitor Camera | Smart Night Vision | 360 Visual Coverage | Motion Detection Two-way Talk | Micro Sd Slot Up To 512gb
Availability:
Out Of Stock
About Product
- Camera TY1 Pro 2K⁺ CS-TY1-R105-1J4WF
- TY1 Pro 2K⁺ CS-TY1-R105-1J4WF
- Specifications
- Model CS-TY1-R105-1J4WF
- Camera
- Resolution 4MP/2K Resolution⁺
- Image sensor F1.6@1/3" Progressive Scan CMOS
- Shutter speed Automatic shutter
- Lens 4mm
- Lens mount M12
- Day & Night IR CUT infrared signal filter auto switching
- DNR (Digital Noise Reduction) DNR 3D
- WDR Technology Digital WDR
- Compression technology
- Video compression H.264/H.265
- Video Bitrate Bitrate self-adjusting.
- Additional fees apply for installation requests
Read full description
Description
- Optimal resolution 2560 × 1440
- Aspect ratio Max: 30fps; Self-adjusting during network transmission
- Network
- Smart alarm Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Detection Mode
- Wi-Fi Pairing AP Pairing
- Protocol EZVIZ Cloud Proprietary Protocol
- Interface protocol EZVIZ Cloud Proprietary Protocol
- Interface
- Storage Support Micro SD card (Max 512G)
- Power port TYPE-C
- Wired network RJ45 X 1 (10M/100M Self-adaptive Ethernet Port)
Wi-Fi
- Standard IEEE802.11a, 802.11b, 802.11g, 802.11n,
- Frequency range 2,4 G: 2400~2483,5 MHz5 G: 5150 MHz-5250 MHz
- Channel bandwidth Support 20MHz
- Security WPA/WPA2, WPA-PSK/WPA2-PSK
- Transmission speed 11b 11Mbps, 11g 54Mbps, 11nHT20 MCS7, 11a 54Mbps, 11nHT20 MCS7
- Output power (EIRP) 19 dBm
- Antenna gain 1,9 dBi
- General information
- Operating conditions -10°C to 45°C (14°F to 113°F), Humidity 95% or less (non-condensing)
- Power supply DC 5V / 2A
- Power consumption Maximum 8W
- Infrared Range MAX 10 meters (32.81 ft)
- Size 88 mm x 88,2 mm x 119 mm (3,46” x 3,47” x 4,69”)
- Packing size 103 mm x 103 mm x 168 mm (4,06” x 4,06” x 6,61”)
- Ceiling weight 218 g/7 oz
- Product box includes
- Details in the box - Camera TY1 Pro 2K⁺
- Power adapter
- Power cable
- Drilling template
- Device mounting plate
- Screw set
- Regulatory information
- Quick Guide
Product Code: CS-TY1-R105-1J4WF
Technical Details
| Sensor & Imaging | |
| Effective Pixels | 2560 × 1440 |
| Connectivity | |
| USB Type | TYPE-C |
| Lens & Optics | |
| Lens Mount | M12 |
| Physical Characteristics | |
| Weight | 218 g/7 oz |
| Photo Specifications | |
| Maximum Image Resolution | 4MP/2K Resolution⁺ |
| Shutter Speed Range | Automatic shutter |
| Video Specifications | |
| Maximum Video Resolution | 2560 × 1440 |
| Frame Rates | Max: 30fps |
| Video Format(s) | H.264/H.265 |
| Microphone Type | Two-way Talk |
| Display & Viewfinder | |
| Screen Size | 3,46” x 3,47” x 4,69” |
| Connectivity | |
| Bluetooth | Bluetooth |
| Wi-Fi | IEEE802.11a, 802.11b, 802.11g, 802.11n |
| Physical Characteristics | |
| Dimensions (W x H x D) | 88 mm x 88,2 mm x 119 mm (3,46” x 3,47” x 4,69”) |
| Storage | |
| Compatible Memory Card Type(s) | Micro SD card |
| Number of Card Slots | 1 |
